NetLight Series Fiber Patch Cords

Product Overview

NetSource’s NetLight Series fiber jumpers are our most economical line of fiber patch cables. These are kept in stock and are often able to ship same day. NetLight jumpers are stocked in meter lengths between 1 and 30 meters. Custom lengths and specifications are available at the same economical price point and typically carry a 5-7 day lead time.

Connector Types: LC, LC-Uniboot, SC, ST, FC with UPC or APC polish
Fiber Types: Singlemode (OS2), Multimode (OM1–OM5)
Cable Type: Indoor Simplex and Duplex
Jacket Options: Riser (OFNR), Plenum (OFNP), LSZH
Jacket Sizes: 1.6mm, 2.0mm, 3.0mm

Optical Performance:
1. FOTP-171 (TIA/EIA-455-171) – Insertion Loss
2. FOTP-107 (TIA/EIA-455-107) – Return Loss
Endface Geometry & Inspection:
1. IEC 61300-3-35 – Visual Inspection
2. IEC 61755-3-1 – Endface Geometry — Single-Fiber
3. IEC 61755-3-32 – Endface Geometry — MT Ferrules (Multifiber)
Environmental/Mechanical (Connectors & Assemblies):
1. GR-326 – Single-Fiber Connector Performance, Durability & Mechanical Requirements
2. GR-1435 – Multifiber Connector Performance, Durability & Mechanical Requirements
Indoor Cable Requirements:
1. UL 1666 / NFPA 262 – Indoor Fiber Cable Flame & Smoke Requirements (Riser & Plenum)
Environmental Compliance:
1. RoHS/REACH – Environmental Compliance

Part Number Chart

Options Type	Glass Type	Cable Type	–	Connector Type Side 1 & 2		–	Length
NL: NetLight	XG: OM3 50um	No letter equals Riser		FA: FC/APC	FA: FC/APC		XXXFT
	4G: OM4 50um	P: Plenum Round Micro Distribution		FC: FC	FC: FC		XXXM
	5G: OM5 50um	LSZH: Low Smoke Zero Halogen		LA: LC/APC	LA: LC/APC
	SM: Single Mode			LC: LC	LC: LC
	62: OM1 62.5			LU: LC Uniboot	LU: LC Uniboot
				SA: SC/APC	SA: SC/APC
				SC: SC	SC: SC
				ST: ST	ST: ST
